FORD WATERPOMP FPX30
FORD WATERPOMP
FPX30
- Single Cylinder. 4 Stroke, OHV, Air Cooled 76dBA
- Low Oil Shut down: Yes
- Pump type: Centrifugal, Self-priming
- Bore and stroke: 70 mm x 54 mm
- Volute: Rigid Mounted Cast Iron
Adviesprijs : € 945,00
| Model |
FPX30
|
|||
|
ENGINE
|
BFT
|
|||
|
Bore and stroke
|
77mm (2.75”) X 54mm (2.13”)
|
|||
|
Displacement(cc)
|
208
|
|||
|
Engine Type
|
Single cylinder, 4-Stroke, OHV, Air Cooled
|
|||
|
Max. Power
|
4.3kW/3600rpm
|
|||
|
Max. Torque
|
13.5N.m/2800rpm
|
|||
|
Compression Ratio
|
8.5:1
|
|||
|
Speed (rpm)
|
≥3600
|
|||
|
No Load Speed (rpm)
|
2850± 50
|
|||
|
Section Port Diameter (mm)
|
80 (3inch)
|
|||
|
Discharge Port Diameter (mm)
|
80 (3inch)
|
|||
|
Total Head li (m)
|
30
|
|||
|
Suction Head Li (m)
|
7
|
|||
|
Discharge Capacity (m3 /h)
|
58
|
|||
|
Cooling System Ignition
|
Forced Air
|
|||
|
Noise Level (dB)
|
≤76
|
|||
|
Fuel Capacity
|
1.3L
|
|
||
|
Pump Type
|
Centrifugal, Self-priming
|
|||
|
Net Weight (Kg)
|
31
|
|||
